Flanges
Flanged and ring-shaped components made around their connection faces, bores and the features that locate them in an assembly.
01 / THE COMPONENT
Defined faces. Connected assemblies.
- Outer diameters, central bores and stepped sections reviewed together.
- Connection faces and seating surfaces identified as functional features.
- Hole patterns and additional machining assessed against the supplied drawing.
Photographs show examples from our product range. Share your drawing to discuss a specific component.
Discuss your component02 / MANUFACTURING ROUTE
From geometry
to production.
The drawing, material and quantity guide the route. We confirm the required operations during the technical review.
- 01
Turning & boring
- 02
Milling or drilling
- 03
Secondary operations
- 04
Dimensional & profile checks
03 / BEFORE WE MAKE IT
The right details
from the start.
A clear drawing helps us focus the review. These are the details most useful for your flanges inquiry.
- Flange diameter, thickness, bore and any stepped or raised faces.
- Hole positions and the reference datums used to control them.
- Mating-part details and any specified flatness, finish or sealing requirements.
- Your drawing revision, expected quantity and target delivery date.
Materials reviewed include SAE 1008–1045 steels, 10B21, SCM435, stainless steel and brass. Suitability is confirmed for the individual component.
Washers and spacing components specified around the surfaces they contact and the dimensions needed in the assembled joint.
Screw components reviewed from the drive and head through to the thread and end detail, with a manufacturing route matched to the drawing.
A drawing does not need to fit a standard catalog. We review custom metal components and bring the required forming, machining and inspection steps together.
